产品分类
MXH SERIES(三通道)
技术参数
|
型号Model |
MXH-315 | MXH-420 | MXH-630 | MXH-510 | MXH-613 |
|
立体声输出功率 8Ω Stereo Power |
300Wx2+150W |
400Wx2+200W |
600Wx2+300W |
500Wx2+1000W |
650Wx2+1300W |
|
立体声输出功率 4Ω Stereo Power |
450Wx2+230W |
600Wx2+300W |
900Wx2+450W |
750Wx2+1500W |
1000Wx2+2000W |
|
桥接输出功率 8Ω Bridged mono output |
900W+150W |
1200W+200W |
1800W+300W |
1500W+1000W |
2000W+1300W |
|
信噪比S/N Ratio |
105dB |
105dB |
105dB |
105dB |
110dB |
|
转换速率 Conversion Rate |
50v/μS |
50v/μS |
50v/μS |
60v/μS |
60v/μS |
|
阻尼系数 Damping Factor |
500:1 |
500:1 |
500:1 |
550:1 |
600:1 |
|
频率响应Frequency Response |
20Hz-20KHz(+/-0.5dB) |
||||
|
总谐波失真THD |
≤0.05%Rated Power@8Ω 1KHZ |
||||
|
互调失真IMD |
≤0.01%Rated Power@8Ω |
||||
|
输入灵敏度 Input Sensitvity |
0.775v. 1.0v. 1.44v |
||||
|
输入阻抗 Input Impedance |
20KΩ(Balance)/10KΩ(Unbalance) |
||||
|
串音Crosstalk |
≤-80dB | ||||
|
保护功能protection |
直流，短路，超温，压限，软启动等DC,Short,corcuit,Temperature,ClipLimiter,Slow start |
||||
|
重量Weight |
16kg |
19kg |
22kg |
27kg |
30kg |
|
尺寸Dimensions(WxDxH) |
483x460x89mm |
||||
