VA SERIES 专业功放
技术参数
|
型号Model |
VA812 | VA830 | VA840 | VA860 | |
|
立体声输出功率 8Ω Stereo Power |
800Wx2+1200W |
300Wx4 |
400Wx4 |
600Wx4 |
|
|
频率响应Frequency Response |
20Hz-20KHz(+/-0.5dB) |
||||
|
总谐波失真THD |
≤0.03%Rated Power@8Ω 1KHZ |
||||
| 互调失真IMD | ≤0.01%Rated Power@8Ω | ||||
|
输入灵敏度 Input Sensitvity |
0.775v. 1.0v . 1.44v | ||||
|
输入阻抗 Input Impedance |
20KΩ(Balance)/10KΩ(Unbalance) |
||||
| 串音Crosstalk | ≤-70dB | ||||
|
保护功能protection |
直流，短路，超温，压限，软启动等DC，S红儿 circuit，Temperature,Clip Limiter,Slow start |
||||
|
重量Weight |
21kg |
19kg |
20kg |
21kg |
|
|
尺寸Dimensions(WxDxH) |
483x430x88mm |
||||
型号Model
VA880
VA8100
VA8130
立体声输出功率 8Ω Stereo Power
800Wx4
100Wx4
1300Wx4
频率响应Frequency Response
20Hz-20KHz(+/-0.5dB)
总谐波失真THD
≤0.03%Rated Power@8Ω 1KHZ
互调失真IMD
≤0.01%Rated Power@8Ω
输入灵敏度 Input Sensitvity
0.775v. 1.0v . 1.44v
输入阻抗 Input Impedance
20KΩ(Balance)/10KΩ(Unbalance)
串音Crosstalk
≤-70dB
保护功能protection
直流，短路，超温，压限，软启动等DC，S红儿 circuit，Temperature,Clip Limiter,Slow start
重量Weight
24kg
31kg
33kg
尺寸Dimensions(WxDxH)
483x430x88mm
