MXH SERIES(three-channel)
Specifications
|
Model |
MXH-315 | MXH-420 | MXH-630 | MXH-510 | MXH-613 |
|
8Ω Stereo Power |
300Wx2+150W |
400Wx2+200W |
600Wx2+300W |
500Wx2+1000W |
650Wx2+1300W |
|
4Ω Stereo Power |
450Wx2+230W |
600Wx2+300W |
900Wx2+450W |
750Wx2+1500W |
1000Wx2+2000W |
|
8Ω Bridged mono output |
900W+150W |
1200W+200W |
1800W+300W |
1500W+1000W |
2000W+1300W |
|
S/N Ratio |
105dB |
105dB |
105dB |
105dB |
110dB |
|
Conversion Rate |
50v/μS |
50v/μS |
50v/μS |
60v/μS |
60v/μS |
|
Damping Factor |
500:1 |
500:1 |
500:1 |
550:1 |
600:1 |
|
Frequency Response |
20Hz-20KHz(+/-0.5dB) |
||||
|
THD |
≤0.05%Rated Power@8Ω 1KHZ |
||||
|
IMD |
≤0.01%Rated Power@8Ω |
||||
|
Input Sensitvity |
0.775v. 1.0v. 1.44v |
||||
|
Input Impedance |
20KΩ(Balance)/10KΩ(Unbalance) |
||||
|
Crosstalk |
≤-80dB | ||||
|
protection |
Direct current, short circuit, over temperature, pressure, soft start, etc,DC,Short,circuit,Temperature,ClipLimiter,Slow start |
||||
|
Weight |
16kg |
19kg |
22kg |
27kg |
30kg |
|
Dimensions(WxDxH) |
483x460x89mm |
||||
