MXH SERIES(Four channels)
Specifications
|
Model |
MXH-930 |
MXH-940 |
MXH-950 |
MXH-960 |
MXH-980 |
MXH-640 |
|
8Ω Stereo Power |
300Wx4 |
400Wx4 |
500Wx4 |
600Wx4 |
800Wx4 |
600Wx2+400Wx2 |
|
4Ω Stereo Power |
450Wx4 |
600Wx4 |
750Wx4 |
900Wx4 |
1200Wx4 |
900Wx2+600Wx2 |
|
8Ω Bridged mono output |
900Wx2 |
1200Wx2 |
1500Wx2 |
1800Wx2 |
2400Wx2 |
1800W+1200W |
|
S/N Ratio |
105dB |
105dB |
105dB |
105dB |
110dB |
110dB |
|
Conversion Rate |
50v/μS |
50v/μS |
60v/μS |
60v/μS |
70v/μS |
70v/μS |
|
Damping Factor |
500:1 |
500:1 |
550:1 |
550:1 |
600:1 |
600:1 |
|
Frequency Response |
20Hz-20KHz(+/-0.5dB) |
|||||
|
THD |
≤0.05%Rated Power@8Ω 1KHZ |
|||||
|
IMD |
≤0.01%Rated Power@8Ω |
|||||
|
Input Sensitvity |
0.775v. 1.0v . 1.44v |
|||||
|
Input Impedance |
20KΩ(Blance)/10KΩ(Unbalance) |
|||||
|
Crosstalk |
≤-80dB | |||||
|
protection |
Direct current, short circuit, over temperature, pressure, soft start, etc,DC,Short circuit,Temperature,Clip Limiter,Slow star |
|||||
|
Weight |
20kg |
23kg |
26kg |
28kg |
30kg |
27kg |
|
Dimensions(WxDxH) |
483x460x89mm |
|||||
