Receiver specification:
Chassis Specification: EIA Standard
Channel Group: Single Channel, Double Channel
Frequency stability: +0.005%, PLL phase-locked loop frequency control
Carrier band: UHF 470-960MHz
Preset digital audio equalizer can simulate the sound quality characteristics of various headers
Modulation mode: FM
Working Effective Distance: 80m for Single-Channel and Dual-Channel Wireless Systems
Oscillation mode: PLL phase locked frequency synthesis
Sensitivity: > 95 dB
When input 1K (MOD) 25mV, S/N > 50dB
Bandwidth: 300MHz
Maximum offset: +50KHz
Comprehensive S/N Ratio > 108 dB Comprehensive T.H.D. < 0.4%@ 1KHz
Output socket: 6.35
Combined Frequency Response: 55Hz-16KHz+3dB
Power supply: 100-240V AC50/60 Hz, 10W
Weight: 1.4KG
Size: 421 mm (wide) X 43mm (high) X 206 mm (deep)
Microphone Specification:
Carrier band: UHF 640-690MHz
Oscillation mode: PLL phase locked frequency synthesis; harmonic radiation < 63dBm;
Bandwidth: 300MHz; Maximum offset: +75KHz
Head: Moving coil type, heart type directivity/capacitance type, heart type directivity;
RF power output: 10mW; battery: AA X 2;
Current consumption: 100mA (typical); battery power consumption/life: about 10 hours
Size: Handheld Mimi 51 (phi) X 256 (long); Waist bag 65 X 195, seat Mimi rod length 39 cm
Weight: 300 g in hand, 115 g in waistband;
