Q4
Applications
conference room, multi-function hall, auditorium, music bar, home theater and shopping mall, etc.
Specifications
| Model | celling-mounted speaker Q4 |
|
Drivers |
LF/ HF: 4.5"*1 |
|
Rated Power |
60W |
|
MAX power |
120W |
|
Nominal impedance |
8 ohms |
|
Frequency Range |
100Hz-20KHz |
|
Sensitivity(1m/1W) |
93dB(1m/1W) |
|
MAX SPL |
114dB |
|
Dispersion(HxV) |
90°*90° |
| Construction | |
| Enclosure Material | High density pine board + brushed aluminum |
|
Enclosure Grille |
White round hole dust proof metal mesh with breathable mesh cloth |
|
Finish |
Black matte, waterproof, wear-resistant painting (customized color according to customer requirements) |
|
Dimensions（mm) |
Diameter:230mm, Height:105mm |
|
Net weight (Kg) |
2.4Kg |
