Model

AQ10B

Drivers　

1×10”

Rated Power

200W

Nominal impedance

 4ohms

Frequency Range

 25Hz-260Hz

Sensitivity(1m/1W)

 94dB

MAX SPL

 120dB

Connection mode

Crystal terminal

Dimensions(W*D*H)（mm)

W350×D420×H445mm

Net weight (Kg)

 19.5Kg
